Adams Rite 2290-310-1ME-32D Dual Force Lock with Standard Flat Strike, Trim Set and 1-1/8″ Backset for Wood or Hollow Metal Doors in Satin Stainless

The 2290-310-1ME-32D from Adams Rite is a Dual Force Lock with Standard Flat Strike, Trim Set and 1-1/8″ Backset for Wood or Hollow Metal Doors in Satin Stainless. The 2290 series Deadlock/Deadlatch combines the access control capabilities of a latch with the security of a deadbolt for wood or hollow metal doors. The key retracts and extends the deadbolt (and deadlatch) from either side. The exterior lever retracts the latch only while the inside lever retracts the deadbolt and latch simultaneously for fast, easy, panic-proof exiting. It operates in such a way that the latch holdback feature is activated or deactivated by turning key to retract latch and sliding holdback button on faceplate down to hold and up to release. It is intended for out-swinging doors.

Features

• Finish: Satin Stainless finish enhances durability and aesthetics.
• Cylinder Backset: 1-1/8″ cylinder backset allows compatibility with standard door preparations.
• Trim Set: Complete trim set included for easy installation and a polished look.
• Faceplate Dimensions: Faceplate measures 1-1/4″ x 8″ for a secure fit.
• Stainless Steel Auxiliary Deadlatch Pin: Prevents “loiding” or case-knife entry, enhancing security.
• Dual Force Operation: Operable by any standard 1-5/32″ diameter mortise cylinder with MS cam for versatile use.
• Minimum Door Thickness: Requires a minimum door thickness of 1-3/4″ for robust installation.
• Grade 1 Strength: Built to meet Grade 1 strength standards for maximum durability.
• Latchbolt Material: Solid brass latchbolt with 5/8″ throw, reversible for convenience.
• Deadbolt Material: Stainless steel deadbolt with 1″ throw for superior locking capability.
• Included Strike: Standard flat strike furnished is the 2206 (ASA) for a flush closing door.

Adams Rite 2290-310-1ME-32D Specifications
