Adams Rite EX76-R335 Standard Concealed Vertical Rod Exit Device, 36″ Regular in Black Anodized

The EX76-R335 from Adams Rite is a standard concealed vertical rod exit device, 36″ regular in black anodized. The EX76 CVR Exit Device is designed for narrow stile aluminum applications that require a life-safety exit device with concealed vertical rods for two-point locking. The EX76 design features easily adjustable concealed rods and latching assembly designed for easy installation, maintenance, and adjustment. When the door closes, the latching assemblies extend into the header and threshold, locking the door at two points. When the active pushbar is depressed, both the top and bottom latching assemblies are retracted, allowing the door to open. Designed for use on single or pairs of doors. Suitable for low, medium and high traffic areas on aluminum and hollow metal applications.

Features

• Active pushbar and back bar: Made of extruded aluminum for durability and strength.
• Non-handed design: Allows for flexibility in installation on either left or right-hand doors.
• Thick door kit: Required when used with cylinder in doors over 1-3/4″ to ensure proper functionality.
• Tall door kit: Necessary for doors taller than 96″, accommodating maximum door heights up to 120″.
• Standard dogging: Operated with a 3/16” hex key for easy access and security.
• Easy installation: Device mounts using standard type ‘F’ self-tapping screws and machine screws.
• Mounting end cap: Features a 1/4″ overlap for effective cut coverage during installation.
• Versatile hardware kit: Suitable for aluminum, hollow metal, and wood door applications for broad compatibility.
• Hardened steel header strike: Ensures enhanced security and durability against tampering.
• Compatible cylinders: Cylinders with MS® cams can be readily obtained from most manufacturers for ease of replacement.
• Entry trim compatibility: Compatible with Adams Rite 3080 Series and 3090 Series Entry Trim for additional customization.
• Impact bumpers: Reduce noise from device activation, improving user experience.
