The RT-05E from American Fibertek is a transmits single direction line level audio, 600 ohms balanced or unbalanced, on one multimode or single mode fiber. The audio is transmitted over the link using FM modulation which results in an improved signal to noise ratio and a constant audio output level over the full optical loss budget.
Diagnostic indicators provide a quick visual check of system status. The rack card transmitter is available in both single channel and two channel versions. Also available is a module receiver with an integrated 5-watt 70V speaker output capability.
American Fibertek RT-05E Audio Rack Card Tx Features
- Feature: Line Level 600 Ohm Balanced or Unbalanced Audio – Ensures compatibility with various audio systems for optimal audio transmission quality.
- Feature: Diagnostics: Audio Level, DC Power, and Optical Presence – Provides real-time system monitoring for quick troubleshooting, enhancing reliability.
- Feature: No user or installation adjustments – Simplifies setup and operation, making it user-friendly for all skill levels.
- Feature: ST Optical Connector – Facilitates easy integration with existing fiber optic systems for seamless connectivity.
- Feature: Compatible with AFI Series 05B – Ensures versatility and flexibility in system design and expansion.
American Fibertek RT-05E Detailed Specifications
| Audio Transmission | Single direction line level audio |
| Impedance | 600 Ohms balanced or unbalanced |
| Modulation Type | FM modulation |
| Optical Connector | ST connector |
| Channel Options | Single channel and two channel versions available |
| Diagnostic Indicators | Audio Level, DC Power, Optical Presence |
| Speaker Output Capability | 5-watt 70V output integrated in module receiver |
