American Fibertek RT-82 16 Channels Contact Closure System with Power Fail Safe

American Fibertek RT-82 16 Channels Contact Closure System Features

The American Fibertek 82 Series multiplexes 16 channels of dry latching contact closure on one multimode fiber. A user-selectable feature allows the contact status to be maintained unchanged or reset through power-cycle and loss-of-optical-power. A reset button is available to clear all contact status to the default state. Individual channel LEDs on the transmitter and the receiver units indicate the channel status. These systems require no field adjustments at installation or additional maintenance thereafter. Diagnostic indicators provide a quick visual indication of system status. Equipment may be ordered as standalone modules or rack cards that are mounted in the SR-20D/2 or SR-20R/1 AFI Card Cages.

Features

• Feature: Form-C (Normally Open or Normally Closed) Dry Contact Closure – Provides flexibility in system integration based on user requirements.
• Feature: Latching Relays reduce power requirement – Enhances energy efficiency and reduces operational costs.
• Feature: User-Selectable feature maintains Contact Status through Power-Cycle and Loss-of-Optical-Power – Ensures uninterrupted operation and reliability during power interruptions.
• Feature: User Control to Reset all Contact Status – Allows for easy maintenance and management of system status.
• Feature: Diagnostics: DC Power, Optical Presence, and Channel Indicators – Offers real-time monitoring of system health and performance.
• Feature: High Density DB26 Data Connector with Adaptor to screw terminal – Simplifies connections and enhances compatibility with existing systems.

American Fibertek RT-82 16 Channels Contact Closure System Specifications
