The ComNet™ FVR1010M1SHR Digitally Encoded Video Receiver/Data Transceiver offers exceptional performance for medium haul video transmission with its innovative features. It supports a 10-bit digital video channel and a bi-directional data channel, ensuring high-quality signal transfer over long distances. Designed with a user-friendly plug-and-play architecture and the capability to daisy chain multiple transmitters and receivers, this device guarantees reliable operation with fail-safety through its Self-Healing Ring topology.
ComNet FVR1010M1SHR Video and Data Features
- One 10-bit digital video channel: Ensures high-quality video transmission, providing clear and detailed visuals.
- One bi-directional data channel; or 8 contact closures: Facilitates two-way communication and increased connectivity options.
- Daisy chain 8 video links on one single mode or multimode fiber: Maximizes fiber use and reduces infrastructure costs.
- Dual optical port Self-Healing Ring (SHR) configuration: Provides fail-safe operation and redundancy in case of fiber or module loss.
- Exceeds all requirements for RS-250C medium haul transmission: Guarantees reliability and performance in demanding environments.
- Compatible with all NTSC, PAL, or SECAM CCTV camera systems: Ensures versatility and ease of integration with existing systems.
- Tested and certified for environmental compliance with NEMA TS-1/TS-2: Ensures durability and functionality in various conditions.
- Voltage transient protection: Safeguards the device from power surges and transients.
- Automatic resettable fuses: Enhances safety and minimizes downtime due to power issues.
- Hot-swappable rack modules: Simplifies maintenance and upgrades without impacting system operation.
- Interchangeable between stand-alone or rack mount use: Offers flexible installation options to meet user needs.
- Distances up to 30 miles (48 km): Enables long-range video transmission, ideal for expansive setups.
- Bi-color (Red/Green) LED status indicators: Provides quick visual feedback on operational status, enhancing user experience.
Detailed Specifications for ComNet FVR1010M1SHR
| Feature | Details |
| Video Channel | 10-bit digital video |
| Data Channel | Bi-directional, supports RS232, RS422, 2-wire and 4-wire RS485 |
| Daisy Chain Capability | Up to 8 video links on single or multimode fiber |
| Self-Healing Ring Topology | Dual Optical Port configuration |
| Transmission Distance | Up to 30 miles (48 km) |
| Environmental Compliance | NEMA TS-1/TS-2 and Caltrans Specification certified |
| Power Protection | Voltage transient protection with automatic resettable fuses |
| Mounting Options | Wall, rack-mounted, or DIN-rail with adapter |
| LED Indicators | Bi-color (Red/Green) for quick status updates |
