Comnet FVR1010S1SHR Digitally Encoded Video Receiver/Data Transceiver, SHR, SM

The ComNet™ FVR1010SHR series of optical video links provides 10-bit digital video, 6.5 Mhz bandwidth, medium haul video quality, one bi-directional data channel and a “Dual Optical Port” (DOP) Self-Healing Ring (SHR) topology. Up to (8) video transmitters and multiple video receivers can be “Daisy Chained” on one optical fiber. The Self-Healing Ring (SHR) topology using the Dual Optical Ports (DOP) provide fail safe operation in the event of loss of one fiber or one optical module. Each optical port uses wavelength division multiplexing (WDM) to both transmit and receive on one optical fiber. The data channel supports RS232, RS422 and 2 wire and 4 wire RS485. Plug-and-play design ensures ease of installation and no electrical or optical adjustments are ever required. Bi-color (Red/Green) LED indicators are provided for confirming operating status. Packaged in the exclusive ComNet ComFit housing, these units may be either wall or rack-mounted, or may be DIN-rail mounted by the addition of ComNet model DINBKT1 adaptor plate.

ComNet FVR1010SHR Features

• 10-bit digital video channel: Provides superior image quality for enhanced clarity.
• Bi-directional data channel: Supports enhanced functionality with the ability to handle 8 contact closures.
• Daisy chain capability: Allows up to 8 video links on a single mode or multimode fiber, optimizing fiber utilization.
• Dual optical port Self-Healing Ring (SHR): Ensures reliable operation even in the event of fiber loss.
• Medium haul transmission compliance: Exceeds all requirements for RS-250C, ensuring robust performance.
• Compatibility: Works with all NTSC, PAL, or SECAM CCTV camera systems for versatile application.
• Environmental compliance: Independently tested and certified, providing peace of mind in various conditions.
• Voltage transient protection: Safeguards against surges on all power and signal lines.
• Automatic resettable fuses: Enhance safety on all power lines.
• Hot-swappable rack modules: Allow for convenient upgrades without downtime.
• Flexible mounting options: Interchangeable between stand-alone or rack mount use with ComFit design.
• Extended network reach: Distances up to 30 miles (48 km) for broad coverage.
• Bi-color LED status indicators: Enable quick operational checks for ease of monitoring.

ComNet FVR1010SHR Specifications
