Comnet FVR40D2I1C4E 4 Video Bi-directional Data Aiphone Intercom 4 Contact Closure 100Mb Ethernet SFP

The Comnet FVR40D2I1C4E environmentally hardened units provide transmission of four independent video channels and two bi-directional data channels. They also provide transmission of one Aiphone intercom channel and four contact closure channels with tamper supervision in addition to one 10/100Mbps Ethernet channel. The FVR40D2I1C4E has dual SFP optical ports to provide a redundant point-to-point fail safe topology in the event of loss of one fiber or one optical module. Plug-and-play design ensures ease of installation and no electrical or optical adjustments are ever required.

Features

• 4 channels of 10-bit digital video encoding and decoding for high-quality video transmission that meets the requirements of EIA RS-250C for short-haul video transmission
• 2 Bi-directional data channels supporting RS232, RS422, and 2 or 4-wire RS485 with tri-state data interfaces
• Duplex Aiphone intercom channel
• Four contact closure channels with supervision
• True 100Mb Ethernet channel
• Dual SFP optical ports redundant Point-to-Point configuration
• Exceeds all requirements for RS-250C short-haul transmission
• Voltage transient protection on all power and signal input/output lines provides unconditional protection from power surges and other voltage transient events
• Bi-color (Red/Green) LED status indicators provide rapid indication of critical operating parameters in addition to alarm contacts for fault monitoring
• Operational status monitored via web management interface through the addition of the ComNet network managed chassis and network management interface module
• Hot-Swappable Modules
• Interchangeable between stand-alone or rack mount use –ComFit
