The Panasonic T2MK7F8QMC Access Control Power Supply Kit is a comprehensive solution designed for efficient access control systems. This kit includes a Trove2 enclosure, an eFlow104NB power supply, and various modules that provide reliable power and management for your access devices. It combines robust features like fire alarm disconnect, overvoltage protection, and multiple power outputs, ensuring optimal performance and safety for your security infrastructure.
Panasonic T2MK7F8QMC Kit Features
- Trove2 enclosure with TM2 & Mercury backplane: Accommodates a variety of Mercury boards including LP1502 and MR52, providing flexibility for your access control needs.
- Complete power management: Includes a removable TM2 backplane and allows for easy integration with various power supplies and sub-assemblies.
- eFlow104NB Power Supply: Converts 120VAC to 24VDC with 10A supply current, ensuring consistent power delivery to your devices.
- Automatic battery switch-over: Instantaneous transfer to standby battery during AC failure ensures uninterrupted operation.
- Supervised Fire Alarm Disconnect: Provides enhanced safety by allowing for emergency egress and alarm monitoring with selectable output options.
- ACM8 Control Module: Converts one input to eight independently controlled outputs, maximizing compatibility with various access control hardware.
- VR6 Voltage Regulator: Outputs a regulated 5VDC or 12VDC at up to 6A, reducing costs by eliminating the need for additional power supplies.
- PDS8 Power Distribution Modules: Distributes power from two sources to eight outputs, ensuring efficient management of power across devices.
Detailed Specifications for Panasonic T2MK7F8QMC Kit
| Feature | Details |
| Trove2 Enclosure | Accommodates multiple Mercury boards and power supplies. |
| eFlow104NB Input | 120VAC, 60Hz, 4.5A. |
| eFlow104NB Output | 24VDC, 10A continuous supply current. |
| Auxiliary Output | Power-limited output rated @ 1A (unswitched). |
| Over Voltage Protection | Prevents damage to connected devices. |
| Battery Backup | Automatic switch to stand-by battery, no interruption. |
| Fire Alarm Disconnect | Supervised with selectable latching options. |
| ACM8 Outputs | Eight independently controlled, fuse-protected outputs. |
| VR6 Output | Selectable 5VDC or 12VDC up to 6A supply current. |
| PDS8 Distribution | Eight fused protected outputs from two power sources. |
