Pelco KBDKIT-X Matrix Keyboard CM6700/MUX Wirekit 220 Features
The KBDKIT-X from Pelco is a remote keyboard wiring kit designed for seamless integration with KBD300A keyboards, ensuring reliable communication and optimal performance. This kit includes essential components for easy setup and functionality, making it an ideal choice for both Direct Mode applications and SCU connections.
- Compatibility: Works with KBD300A keyboards and SCU (CM6700/CM6800 Mode), ensuring broad usability in various systems.
- Long Distance Communication: Supports RS-422/RS-485 communication over distances up to 4,000 feet (1,219 m) using 24-gauge wire, making it suitable for large installations.
- Essential Components Included: Comes with two RJ-45 wall blocks and one 120 VAC to 12 VAC transformer for convenient setup and operation.
- Shielded Twisted Pairs Cable: Requires the use of shielded twisted pairs cable that meets RS-422/RS-485 standards for enhanced signal integrity.
- Direct Mode Support: Ideal for configurations requiring a single keyboard in Direct Mode applications, providing versatility in installation options.
Pelco KBDKIT-X Detailed Specifications
| Product Type | Remote Keyboard Wiring Kit |
| Model | KBDKIT-X |
| Compatibility | KBD300A keyboards, SCU (CM6700/CM6800 Mode) |
| Cable Distance | Up to 4,000 feet (1,219 m) |
| Cable Requirement | 24-gauge wire |
| Included Components | Two RJ-45 wall blocks, one 120 VAC to 12 VAC transformer |
| Installation Mode | Direct Mode and SCU connections |
| Cable Type | Shielded twisted pairs cable |
